| 型號(hào) Model | 庫存 | 尺寸Size (mm) | 刀片 Insert | 刀墊 Shim | 銷釘 Lock pin | 壓板 Clamp | 雙頭螺栓 Clamp screw | 扳手 Hex wrench | |||||||
| 右刀 Right hand | 左刀 Left hand | R | L | a | b | L | h | f | e | ||||||
| MCLNR1616H12 MCLNR2020K12 MCLNR2525M12 MCLNR3232P12 | MCLNL1616H12 MCLNL2020K12 MCLNL2525M12 MCLNL3232P12 | ● ● ● ● | ○ ● ● ● | 16 20 25 32 | 16 20 25 32 | 100 125 150 170 | 16 20 25 32 | 20 25 32 40 | 32 32 32 32 | CN..1204.. | ICSN-433 | NL-46 | CL-20 | XNS-48 | S1/8,S3/32 |
| MCLNR2525M16 MCLNR3232P16 MCLNR4040R16 | MCLNL2525M16 MCLNL3232P16 MCLNL4040R16 | ○ ● ○ | ○ ● ○ | 25 32 40 | 25 32 40 | 150 170 200 | 25 32 40 | 32 40 50 | 38 38 38 | CN..1606.. | ICSN-533 | NL-58 | CL-12 | XNS-510 | S5/32，S1/8 |
| MCLNR2525M19 MCLNR3232P19 MCLNR4040R19 | MCLNL2525M19 MCLNL3232P19 MCLNL4040R19 | ○ ○ ● | ○ ○ ● | 25 32 40 | 25 32 40 | 150 170 200 | 25 32 40 | 32 40 50 | 38 38 38 | CN..1906.. | ICSN-633 | NL-68 | CL-12 | XNS-510 | S5/32，S9/64 |
| MCLNR4040R25 | MCLNL4040R25 | ○ | ○ | 40 | 40 | 200 | 40 | 50 | 45 | CN..2509.. | ICSN-846 | NL-810 | CL-24 | XNS-610 | S3/16,S5/32 |
